WheelChair Lift I Swivel Lift Seat I Car Mobile Chair for Docking With Wheelchairs I Transfer Patient Directly From The Seat I Complete Set I Meubon
Regular price
$9,900.00 USD
Regular price
$11,000.00 USD
Sale price
$9,900.00 USD
Unit price
per
In stock
Wheel Chair Lift I Car Mobile Chair for Docking With Wheelchairs I Allowing Passengers To Transfer Directly From The Seat I for disabled.
This is electric and can move out from the car and can move up and down. Delivery time of 2 weeks
This complete set includes the mechanism, docking wheelchair and seat,
|
Operating voltage: 12V DC
|
10 degree
|
|
Fall time: 24-30S
|
6cm
|
|
Rated Power: 120W
|
73cm
|
|
Rise time: 24-30S
|
Can move laterally
|
|
Rotation time:4-6S
|
Sanyuan lithium battery
|
|
Maximum load: 300lbs
|
6km/h
|
|
Forward time: 16-20S
|
6cm
|
|
Safety Class: IP67
|
adjustable
|
|
Backward time: 16-20S
|
10cm
|
|
Rotation Angle:0-113 degree
|
52cm
|
|
Maximum lowered height:395mm
|
52cm
|
|
Full maximum operating current:17A
|
42cm
|
|
Static sleep current:less than or equal to 0.3ma
|
42cmX42cm
|
|
Noise:less than 70dm during opertion
|
10" omnidirection wheel
|
|
Time required to work one cycle
|
about 2 minutes.
|
|
Packing size:
|
Electric version:128*80*60cm
Manual version:128*80*40cm |
Robot Power chair electric mobility wheelchair
Operating voltage:12V DC
Fall time:24-30S
Rated Power:120W
Rise time:24-30S
Rotation time:4-6S
Maximum load:150kg
Forward time:16-20S
Safety Class:IP67
Backward time: 16-20S
Rotation Angle: 0-113 degree
Maximum lowered height: 395mm
Full maximum operating current:17A
Static sleep current: less than or equal to 0.3ma
Noise: less than 70dm during operation
Time required to work one cycle: about 2 minutes.
Packing size:
Electric version: 128*80*60cm
Manual version: 128*80*40cm
Fall time:24-30S
Rated Power:120W
Rise time:24-30S
Rotation time:4-6S
Maximum load:150kg
Forward time:16-20S
Safety Class:IP67
Backward time: 16-20S
Rotation Angle: 0-113 degree
Maximum lowered height: 395mm
Full maximum operating current:17A
Static sleep current: less than or equal to 0.3ma
Noise: less than 70dm during operation
Time required to work one cycle: about 2 minutes.
Packing size:
Electric version: 128*80*60cm
Manual version: 128*80*40cm
Easy to install by 2 people
Available in 2 models: Choose between the model that turns to the left and the model that turns to the right
MINIMUM INSTALLATION SPACE REQUIREMENTS
| Model | Install Position | A (in) | B (in) | C (in) | D (in) | E (in) | Distance from central control to door (in) |
|---|---|---|---|---|---|---|---|
| S-LIFT-R PRO | Middle row | 38.98 | 26.77 | 26.77 | 38.98 | 26.77 | — |
| Driver/passenger seat | 38.98 | 28.35 | 28.35 | 28.35 | 26.77 | 21.65 | |
| S-LIFT-L PRO | Middle row | 38.98 | 26.77 | 26.77 | 38.98 | 26.77 | — |
| Driver/passenger seat | 38.98 | 28.35 | 28.35 | 28.35 | 26.77 | 23.62 |
PRODUCT MANUAL SHOWING INSTALLATION STEPS
https://drive.google.com/file/d/15UcAqHnWCOxPWtYWPSPPJiFvmaTDiXOB/view?usp=sharing
https://drive.google.com/file/d/15UcAqHnWCOxPWtYWPSPPJiFvmaTDiXOB/view?usp=sharing
