Pocket Penetrometer – Soil Consistency & Shear Strength Testing Tool (ASTM D2573-94 Compliant)

The Pocket Penetrometer is a compact, reliable tool engineered for quick and accurate field measurements of soil consistency, shear strength, and approximate unconfined compressive strength. Built to meet ASTM D2573-94 standards, this instrument is essential for geotechnical investigations and cohesive soil classification.

🔍 Product Features:

• Measurement Range: 0–4.5 tons/ft² (TSF) or kg/cm²

• Plunger Diameter: 6.35 mm

• Dimensions: 40 × 200 × 50 mm

• Weight: Approx. 1 kg

• Material: Durable anodized aluminum

• Length: 6.25” long with 7/8” diameter

🛠️ How It Works:

1. Slide the ring on the barrel down to rest against the handle.

2. Insert the knurled tip into the soil up to the groove located 1/4” from the point.

3. Read the compression strength directly from the scale—visible at the lower side of the ring (nearest the knurled handle).

4. For very soft soils, use the Adapter Foot and divide the reading by 16 to obtain the correct value.

✅ Benefits:

• Easy-to-read dial scale for fast field readings

• Lightweight design (under 5 oz) for portable use

• Minimizes human error in cohesive soil classification

• Compatible with torsional vane shear testers for internal friction analysis

• Ideal for field inspections, soil surveys, and foundation assessments

📌 Usage Tips:

• Always test on smooth surfaces and hold the penetrometer at a right angle to the soil.

• Take multiple nearby readings and average them for best accuracy.

• Discard any readings that deviate significantly from others.

This rugged, handheld penetrometer is a must-have for geologists, civil engineers, and construction professionals conducting quick field evaluations of soil strength and composition.

• warranty : 1 Year
• model number : BTUHDCP
• power : Hydraulic
• Standard : ASTM/EN//BS
• Warranty : 1 Year
• Application : Soil test
• Accuracy : 1
• Dimensions : 310x1160x190 mm
• Weight : 27 kg
• Minimum Order Quantity : 1 set
