MEUBON

3.5Mhz convex Veterinary ultrasound probe scanner for swine and sheep

$1,250.00 USD
$1,350.00 USD $1,250.00 USD
SAVE 7% SOLD OUT

In stock

wireless type 3.5Mhz convex Veterinary ultrasound probe scanner for swine and sheep
Application in animal husbandry:

* To monitor follicular development and ovulation, provide a reliable scientific basis for when to breed and increase the breeding rate.
* Ultrasound monitoring in early pregnancy, to find non-pregnant timely.
* Pregnancy monitoring can detect stillbirth, miscarriage, embryo absorption etc. Meanwhile it can estimate the number of embryo.
* Perinatal monitoring can determine fetal viability and whether fetal or afterbirth is exhausted.
* Postnatal monitoring of uterine recovery, diagnosis of endometritis, uterine accumulation, effusion and other reproductive disorders.
How the wireless ultrasound probe works?

The wireless probe is a mini ultrasound scanner without a screen. We minimize the components of a traditional ultrasound into a small circuit board built into the probe, and showing image in smart phone/tablet/computer through Wifi transferring(You Don't need internet access). Image can both show in screen and tablet. Image transferring through internal wifi from probe, no need external Wifi signal.

Features of the wireless ultrasound probe:
* Small and Compact size, easy to carry.
* Wireless type without probe cable, working freely. High cost-effective.
* Waterproof design, convenient for sterilization.
*Remote diagnosis convenience, capable for images transfer to doctors.
* Advanced digital imaging technology, clear image.
*Applicable in emergency, clinic, outdoor and vet inspection.
*Intelligent terminal platform, powerful expansion functions on application, storage, communication, printing.
Product Parameters
Specifications of this veterinary wireless convex ultrasound probe(BW):

-Scanning mode: Electronic array
-Display mode: B, B/M, color doppler version with B+ Color, B+PDI, B+PW
-Probe element: 80/128/192
-Channel of RF circuit board: 16/32/64
-Probe frequency and scan depth, scan angle, head radius: 3.5MHz/5MHz, 90/160/220/305mm, 60°, 60mm
-Image Adjust: B Gain, TGC, DYN, Focus, Depth, Harmonic, Denoise, Color Gain, Steer, PRF
-Cineplay: auto and manual, frames can set as 100/200/500/1000
-Puncture assist function: the function of in-plane puncture guide line, out-of-plane puncture guide line, automatic blood vessel
measurement.
-Measure: Length, Area, Angle, heart rate, Obstetrics
-Image save: jpg, avi and DICOM format
-Image frame rate: 18 frames / second
-Battery working time: 3~5 hours(according to different probe and whether keep scan)
-Battery charge: by USB charge or wireless charge, take 2 hours
-Dimension: 156×60×20mm
-Weight: 220g~250g
-Wifi type: 802.11g/20MHz/5G/450Mbps
-Working system: Apple iOS and Android, Windows

Product Configuration :

Standard Configuration：Wireless Ultrasound Scanner x 1 unit, USB Charging Cable x 1pc,Carrying Bag or Aluminium Suitcase(options)x 1pc.
Optional：Stainless Steel Puncture Guide, Android or iOS Phone/Tablet, Windows PC, Wireless Power Bank, Tablet Bracket, Trolley


  • Working platforms : Android phone/tablet, iphone/ipad, windows computer
  • Scanning mode : Electronic array
  • Display mode : B, B/M
  • Frequency : Convex: 3.5/5.0Mhz
  • Display depth : 90/160/220/305mm, 60°, 60mm
  • Image adjust : BGain, TGC, DYN, Focus, Depth, Harmon, Denoise, Steer, PRF
  • Image frame rate : 18 frames/second
  • Battery working time : 3-4 hours,wireless charging(2 hours)
